B302E500 High Resolution Digital Biological Microscope With 100X Water Objective
B302E500 Digital Biological Microscope, for the images of the new coronavirus (SARS-CoV-2) were taken on scanning and transmission electron digital microscopes.
Perfect Optical System
- High resolution and perfect definition from infinity correct optical system
- 100X water objective instead of 100X oil objective, more be convenient for using
Perfect Appearance Design
- Drop-style integrated appearance design, looks elegant
Perfect Ergonomics Design
- Low position operation, convenientfor long-term using
- New wound device for cable, easy to move and keeping
- The changing of objectives can be watched by back side through the back watching window
Technical Data:
| Items | Specification | B302E500 |
| Main Body | | ● |
| Eyepiece | WF10X/20mm (High eyepoint) | ●● |
| Infinity Objective | EPLAN 4X/0.10 | ○ |
| EPLAN 10X/0.25 | ○ |
| EPLAN 40X/0.65(S) | ○ |
| EPLAN 100X/1.25(S,Oil) | ○ |
| PLAN 4X/0.10 | ● |
| PLAN 10X/0.25 | ● |
| PLAN 20X/0.40(S) | ○ |
| PLAN 40X/0.66(S) | ● |
| PLAN 60X/0.80(S) | ○ |
| PLAN 100X/1.25(S,Oil) | ● |
| PLAN 100X/1.15(S,Water) | ○ |
| Butterfly Head | 5 MP Pixel Digital Head, Inclined 30°,Rotatable 360°, Interpupilary Distance: 48-75mm 1/2’’CMOS color sequential scanning. USB2.0 Light Distribution: 20:80 | ● |
| Nosepiece | Quadplex | ● |
| Mechanical Stage | Size 145mmX140mm, Travel Range:76mmX52mm, Scale: 0.1mm, Two Slide Holder | ● |
| Rackless(Integrated) stage, Size: 140×135mm,Travel Range: 75×35mm, Two-slide holder | ○ |
| Abbe Condenser | N.A.1.25, With iris Diaphragm | ● |
| Coaxial Coarse and Fine Focusing Knobs | Coarse Focusing Travel Range: 25mm Fine Focusing Travel Range: 2µm/division | ● |
| Aspheric Illumination | 3W LED Illumination,Voltage: 100V-240V | ● |
| Dark Field Unit | Dark Field Ring (Dry, N.A.0.9) | ○ |
| Polarizing Unit | Analyzer, Polarizer | ○ |
| Wire Winding Device | | ● |
Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.
Packing Size: 345mm×260mm×455mm Gross Weight: 6.7 kgs Net Weight: 5.3 kgs
FAQ 1. Are you a factory or trading company?
We are a factory.
FAQ 2. Can you supply OEM?
OEM is available.
FAQ 3. What's the MOQ ?
(1). MOQ is 1 piece. The disposable supplies order usually at least 1 box.
FAQ 4. How about the order processing and lead time?
After order confirmation and receive the advance payment, we will prepare the machines and goods. Usually could ready within 10 working day, when dispatch, will inform client and send the documents for client making import customs clearance.
FAQ 5. What quality will be ensured?
100% new and quality inspection before delivery from factory.
Stable export box for good package.
FAQ 6. Can you guide the working?
The machine will deliver with English display, English manual and video for installation and operation.
FAQ 7. How can your engineer replace parts if they are not beside the machine?
Bonnin’s engineer could provide the solutions by email and video. In warranty period, we can send spare parts for free and life-time technical support for spare supply.
